Cyanide cyan Stingray x2 rotary machine

Stingray X2 Rotary Tattoo Machine in Cyanide Cyan

Description:
The Stingray X2 has an all new high energy efficient Swiss motor with a 6W mechanical output. This new motor was exclusively designed for the X2 models, making this Stingray more powerful than ever. The Stingray X2 features more advantages than other machine types for easier and more absolute control, one of them being the new patent pending Desmodromic roller cam system. This system gives the artist full linear control at variable speeds while still being able to produce a defined needle motion. This ability makes the Stingray X2 ideal for lining and color packing work.
The Stingray X2 comes with a new stainless steel 4mm stroke cam that is designed to be more durable and have improved performance. The new Desmodromic system allows the artist to control the characteristics and behavior of the machine and needle speed with changing the cam. The Stingray X2 also features an improved stable give adjustment with an all new cap and built-in damper. It is incredibly lightweight at only 90g and ergonomically designed with reduced vibrations.

Core Benefits:
• Lightweight (85 grams)
• Silent
• Low vibrating
• Ergonomic
• Don’t need rubberbands
• Adjustable hitting force
• Accepts standard grips, tubes and needles
• Compatible with cartridge needles
• Both clipcord & RCA connections
• Works with most power supplies 0-13V
• Exchangeable cams
• Normally stops in upper position
• No moving components in contact with plastic barrier
• High durability

Specifications:
Input voltage: 0 - 13 volt DC (max. 13 volt DC)
Power connections: RCA or clipcord (max. clipcord end diam Ø1,6 mm)
Rpm range Stitches / sec: 0 - 8 000 rpm / min 0 - 130 / sec
Stroke length: 2,6 - 3,5 mm depending on cam used
Suspension stroke: 0 - 2 mm
Max. tube diam Ø: Ø8 mm
Max. needle size: 50 magnum
Weight: 85 grams
Wireless ready: Yes
Dimensions LxBxH: 95 x 21 x 77 mm
